Image Sensor

Image Sensor 1/2.8", Progressive Scan, CMOS

Max Resolution

3840x2160

Effective Pixels

8.0MP

Compression Standard

H265/H.264/H.265+/MJPEG

Framerate

30fps

Bitrate

Main Stream: 256Kbps ~ 4096Kbps

Sub Stream: 68Kbps~1024Kbps

Third Stream: 68Kbps~1028Kbps

SNR (dB)

≥50dB

Min. Illumination

0Lux (light ON)

Lens

Lens

Varifocal Lens, Motorized Lens, 2.7mm-13.5mm

Focal lens & FOV

2.7mm-13.5mm     Horizonal FOV: 101.4° to 26.9°

Vertical FOV: 53.6° to 15.2°           Diagonal FOV: 118.7° to 30.5°

Function

Audio Codec

G.711U/G.711A (default)

Exposure Control

Auto

White Balance

Auto

Gain Control

Auto

Digital 3D Noise Reduction

Support

OSD Information Setting

By default: The customized OSD supports a maximum of six lines, each line contains a maximum of 32 characters. One Chinese character is counted as two characters

SNTP

Support

Schedule Reboot

Support

Smart Defog

Support

Smart Motion Detection

Not Support

Image Setting

Support Saturation, Brightness, Contrast, Sharpness adjustment

Image Style

Standard, Soft, Transparent

Day and Night Function

Auto, Always Black & White, Always Color, Scheduled Color

Privacy Mask

Support up 8 areas

Night Vision Optimization

Support

WDR

120dB

Screen Settings

Screen mirroring, Screen flipping

IP Adaptation

Support automatic adaptation of IP address (Optional)

Intelligent Analysis

Not Support

Alarm Method

Email Alarm, Client Alarm

Remote Operation

System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis

Audio Function

Built-in Mic and Speaker

SD Card

Support（512G）

Peripheral Extension Interface

Audio Input/Output, Alarm Input/Output

Network

Ethernet

10/100Mbps Ethernet

Stream

3x Streams

Network Protocols

IPv4, IPv6, HTTP, HTTPS, QoS, SMTP, UPnP, DNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP

Access Protocol

Standard ONVIF, Public Cloud

Network Transmission

CloudSEE 2.0

Fusion Cloud Platform

Support

Browser

IE8+, Chrome18+, Firefox5.0+, Safari5.02+

User

Up to 13 Users

App

Support iOS/Android

General

Lights

4 Warm Light LEDs + 4 IR LEDs

IR Distance

IR: Up to 80 Meters

Warm Light: Up to 60 Meters

Waterproof Level

IP67

Power Supply

DC12V/2A or PoE

Power Consumption

<6W (During Day); <12W (At Night)

Working Temperature

-30℃~60℃(-22℉~140℉)

Working Humidity

10% ~ 90% Rh

Color/Material

Black and White/Metal+Plastic

Dimensions (WxHxD)

103x91x255mm

Weight

732g

Installation Method

Wall or Ceiling Mount
