Operational |
On Board Storage | 64Gb Emmc |
Memory | 16Gb LRDDR4 |
Video Standard | H.265/H.264 |
Scanning System | Progressive |
Image Sensor | 1/1.8' CMOS |
Number of Pixels | 4K (4096 x 2160) |
Min. Illumination | Color: 0.001Lux@F1.2（AGC on） BW: 0.0001Lux@F1.2 (AGC on) |
SNR | ≥50dB |
E-Shutter Speed | 1/3~1/100,000s |
Removable IR-Cut Filter | Yes |
Day/Night | Auto/Day/Night/Timing |
Backlight Compensation | WDR, BLC, HLC |
White Balance | Auto |
Gain Control | Auto |
HDR | ≥90dB |
3D NR | Yes |
Lens | 12-50mm CS Mount DC-Iris Lens |
Digital Image Stabilization | No |
Privacy Masking | Off/On |
Defog | Yes |
Local Storage | Micro SD card slot (512GB) |
USB | Yes, USB2.0*1 |
Alarm Inputs/Outputs | 2 in / 2 out |
TTL | Yes |
RS485 | Yes*1 |
RS232 | Yes*1 |
Indicator | Red and Green |
Reset | Supported |
Video |
Resolution | 4096x2160,1920x1080, 720x576, etc. |
Number of Video streams | 2 |
Frame Rate | 25/30 |
Bit Rate | 32K~8Mbps |
Analog Output Support | No |
Audio |
Audio Compression | G.711 a |
Audio Stream | Full duplex |
Audio Interface | Line in/out |
Network |
Ethernet | 10/100 M Ethernet (RJ-45 *2) |
Supported Web Browsers | Microsoft Edge, Chrome |
Supported OS | Microsoft Windows 10, Windows 11 |
Protocols* | IPv4, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, FTP, DHCP, NTP, Multicast, ICMP, IGMP, 802.1x |
Interoperability | ONVIF |
Maximum Users Access | 32 |
Security | Firmware encrypted, User account and password protection, HTTPS, Digest authentication, AES128/256, SSH/Telnet closed |
Events/Analytics |
NPU | Support, 3.2T@INT8 |
Video Analytics | Standard: Motion detection AI Based: N/A |
Event Linkage | Email, Push notification, SD card recording, Digital output |
Event | Event notification using digital output MicroSD card |
Electrical |
Power Supply | DC 12V, POE (802.3at) |
Power Consumption | 12W Max |
Mechanical |
Dimensions（Box Only） | 149.3 x 84.3 x 70.5 mm (L x W x H) |
Dimensions（Lens Incl.） | 228.9 x 84.3 x 70.5 mm (L x W x H) |
Body Material | Aluminum alloy |
Color | White + Black |
Environmentale |
Operating Temperature | 0 °C ~ 50 °C |
Relative Humidity | 0%~95%, non-condensing |
