  • 32CH 4MN XVR

›

32CH 4MN XVR
JVS-XD2832-HE20K
Message
Features
Specification
Download

Key Features

• AHD, TVI, CVI, CVBS, IP video input

• Automatic networking support

• Cloud services, P2P

• H.264+ (Quasi H.265) video compressions

• Third-party network cameras supported

• Support IVP


Specifications
ModelJVS-XD2832-HE20K
Video and Audio
Analog Camera Input32CH, BNC
HDCVI Camera1080p@25/30fps, 720p@25/30fps
AHD Camera4MP, 1080p@25/30, 720p@25/30fps
TVI Camera1080p@25/30, 720p@25/30fps
CVBS CameraPAL/NTSC
IP Camera InputUp to 1080P
Video Port ConfigurationFull HD: 32CH
Hybrid: 16CH+16CH
Full Network: 32CH
Audio In/Out8/1, RCA
Two-way Talk1CH RCA
Recording
CompressionH.264+/H.264
Resolution4M-N, 1080N, 720p, WD1
Record RateMain Stream: 4M-N(1~8fps), 1080N(1~18fps), 720P/960H/D1(1~18fps）
Sub stream: D1/CIF(1~8/12fps)
Record Mode

Manual, Schedule (General, Continuous), MD (Motion Detection, Video Loss, IVP),

 Alarm Device

Audio CompressionG.711U
Display
Interface1x HDMI, 1x VGA
Resolution1280x1024, 1024x768, 1280x800, 1440x900, 1920x1080
OSDDevice ID, Time, Record Setting, Alarm Setup, Audio,Camera Title
Network
Interface1 RJ45 Port (100M)
Network FunctionTCP/IP, DHCP, DNS, DDNS, HTTPS, HTTP,
Smart PhoneiPhone, Android
InteroperabilityONVIF 2.4
Playback and Backup
Playback8ch 4.0MP/16ch 2.0MP
Search ModeTime /Date, Alarm, MD, IVP, Auto, Scheduled
Playback Function

Day View, Hour View, Back Step, Rewind, Pause, Play,Fast Forward, Slow, Step, Snap

,Sound ON/OFF, Zoom,Backup to U-Disk

Backup ModeUSB
HDD
Interface Type2 SATA Interface
CapacityUp to 6 TB
General
Power SupplyDC12V
Consumption≤ 20W
Working Temperature               00C~ 550C
Working Humidity10% to 90%
Dimensions405x338x135mm
Weight≤ 3Kg



Description


JVS-XD2832-HE20K 32CH 4MN XVR.pdf
