Video |
Image Sensor | 1/1.8" CMOS Sensor |
Max Resolution | 2496x1792 |
Effective Pixels | 5.0MP |
Compression Standard | H.264/H.265(Default) |
Frame Rate | 25fps |
Bitrate | Main Stream: 256Kbps ~ 8192Kbps Sub Stream: 68Kbps~1024Kbps |
SNR (dB) | 50dB |
Min. Illumination | 0Lux (light ON) |
Lens |
Interface Type | Non-standard Interface |
Lens | 40x Optical |
Focal length | 5.3mm-215mm |
Function |
Audio Codec | G.711U/G.711A (Default) |
Exposure Control | Auto |
White Balance | Auto |
Gain Control | Auto |
Digital 3D Noise Reduction | Support |
OSD Information Setting | Large Font OSD, OSD Flashing on Alarm, OSD Position Settings |
SNTP | Support |
Schedule Reboot | Support |
Smart Defog | Support |
Motion Detection | Support Humanoid Detection |
Image Setting | Support Saturation, Brightness, Contrast, Sharpness Adjustment |
Image Style | Standard, Soft, Transparent |
Day and Night Function | Automatic Switching, Timing Switching, Day Mode, Night Mode |
Privacy Mask | Support Up To 24 Masking Areas |
Night Vision Optimization | Support |
DWDR | Support |
Screen Settings | Screen Mirroring, Screen Flipping |
IP Adaptation | Support Automatic Adaptation of IP Address |
Intelligent Analysis | Support Region Intrusion, Line Crossing, Video Tampering Detection |
Alarm Method | Email Alarm, Client Alarm |
Remote Operation | System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis |
External Interface | External Audio Input, External Audio Output |
SD Card | Support（512G） |
Pan/Tilt Range | Pan: 0°～360°; Tilt: -15°～90° |
Pan Speed | 0°～180°/S |
Tilt Speed | 0°～75°/S |
Network |
Ethernet | 10/100Mbps Ethernet |
Stream | 2x Streams |
Network Protocols | HTTP；HTTPS；IPv4；RTSP；UDP；SMTP；NTP；DHCP；DNS；DDN；802.1x；Qos；FTP；UPnP；ICMP；SNMP；IGMP；RTP；PPPoE；RTMP；TCP |
ONVIF | Standard ONVIF |
Network Transmission | CloudSEE 3.0, Onvif |
Browser | IE8+, Chrome18+, Firefox5.0+, Safari5.02+ |
User | Up to 13 Users |
App | Support iOS/Android |
General |
Lights | 13 infrared and laser lights |
Fill Light Distance | Warm Light: 60 Meters IR LED:250 Meters |
Network interface | RJ45*1 SFP*1 |
Alarm interface | Alarm in*2 Alarm Out*2 |
Waterproof Level | IP67 |
Power Supply | DC12V/3.33A or PoE |
Power Consumption | ≤25W |
Working Temperature | -20°C ~ 60°C |
Working Humidity | 0% ~ 93% Rh |
Color/Material | Front Ball Shell: Aluminum Alloy Black; Rear Ball Shell: ABS Black; Bracket: Aluminum Alloy White |
Dimensions (WxHxD) | 400x325x325mm |
Weight | 3500g |
Installation Method | Wall Mount |
