JVS-N53-Z30
5MP Full-Color PTZ IP Camera
Message
Features
Specification
Accessories
Download

Features

  • 5MP Ultra-clear Image Quality

  • 30x Zoom

  • Support SD Card (512GB)

  • 2x Warm Lights + 4x Infrared Lights + 4x Laser Lights; Maximum Fill Light Distance: Infrared 150 Meters, Warm Light 60 meters

  • Perimeter Prevention: Region Intrusion, Line Crossing, Motion Detection

  • Support Humanoid Tracking Zoom Function

  • External Interface: External Audio Input, External Audio Output, Support Two-way Intercom

Specifications
Video
Image Sensor1/3" CMOS Sensor
Max Resolution2496x1792
Effective Pixels5.0MP
Compression StandardH.264/H.265(Default)
Frame Rate25fps
Bitrate

Main Stream: 256Kbps ~ 8192Kbps

Sub Stream: 68Kbps~1024Kbps

SNR (dB)50dB
Min. Illumination0Lux  (light ON)
Lens
Interface TypeNon-standard Interface
Lens30x   Optical
FOVH: 50°, V: 29°, D: 62°
Function
Audio CodecG.711U/G.711A (Default)
Exposure ControlAuto
White BalanceAuto
Gain ControlAuto
Digital 3D Noise ReductionSupport
OSD Information SettingLarge   Font OSD, OSD Flashing on Alarm, OSD Position Settings
SNTPSupport
Schedule RebootSupport
Smart DefogSupport
Motion DetectionSupport Humanoid Detection
Image SettingSupport Saturation, Brightness, Contrast, Sharpness   Adjustment
Image StyleStandard, Soft, Transparent
Day and Night FunctionAutomatic Switching, Timing Switching, Day Mode, Night   Mode
Privacy MaskSupport Up To 24 Masking Areas
Night Vision   OptimizationSupport
DWDRSupport
Screen SettingsScreen Mirroring, Screen Flipping
IP AdaptationSupport Automatic Adaptation of IP Address
Intelligent   AnalysisSupport Region Intrusion, Line Crossing, Video   Tampering Detection
Alarm MethodEmail Alarm, Client Alarm
Remote OperationSystem, Audio and Video, Image, Alarm, Network management,   Storage management, Intelligent Analysis
External InterfaceExternal Audio Input, External Audio Output
SD CardSupport(512G)
Pan/Tilt RangePan: 0°~360°; Tilt: 0°~90°
Pan Speed0°~40°/S
Tilt Speed0°~30°/S
Network
Ethernet10/100Mbps Ethernet
Stream2x Streams
Network ProtocolsHTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
ONVIFStandard ONVIF
Network TransmissionCloudSEE 2.0, GB28181
BrowserIE8+,   Chrome18+, Firefox5.0+, Safari5.02+
UserUp to 13 Users
AppSupport iOS/Android
General
Lights2x   Warm Lights + 4x Infrared Lights + 4x Laser Lights
Fill Light DistanceWarm Light: 60 MetersIR LED:150 Meters
Waterproof LevelIP66
Power SupplyDC12V/3.33A or PoE
Power Consumption ≤25W
Working Temperature-20°C ~ 60°C
Working Humidity0% ~ 93% Rh
Color/Material

Front Ball Shell: Aluminum Alloy Black

Rear Ball Shell: ABS Black

Bracket: Aluminum   Alloy White

Dimensions (WxHxD)390x325x205mm
Weight2820g
Installation MethodWall Mount
