Image Sensor

1/2.9" Progressive CMOS

Min. Illumination

LEDs ON 0 Lux

Day & Night

IR Cut filter with auto switch

Lens

3.6mm/6mm

Viewing Angle

3.6mm H: 82.4°, V: 44.0°, D: 95.9°

6mm H: 53.3°, V: 29.2°, D: 60.4°

Rotation Angle

Pan:  -170° ~ 170°; Tilt:  -9° ~ 110°

LEDs

12x Warm LEDs + 6x IR LEDs

LED Range

IR LED up to 40m, Warm LED up to 30m

Alarm

Blue & Red Warning Lights


Max Resolution

2304x1296

Frame Rate

20fps

Video Compression

H.265/H.264

Bit Rate (CBR/VBR)

Main Stream: 128-4096Kbps. Default 2380Kbps

Sub Stream: 68-1024Kbps. Default 256Kbps

Audio Compression

G.711a / G.711u

Image Setting

Saturation, Brightness, Contrast, Sharpness

Image Enhancement

BLC/HLC/3D DNR/Defog

White Balance

Auto

Privacy Mask

Support 8 Rectangle Areas

DWDR

Support

Network

Network Protocols

HTTP, TCP/IP, UDP/IP, ICMP, RTP, UDP, RTCP, SMTP, DHCP, DNS

Interface Protocols

Standard ONVIF, GB28181, CloudSEE

Auto IP Configuration

Support

Alarm Trigger

Motion Detection, Region Intrusion, Line Crossing, Humanoid Detection, Video Occlusion

RTSP Video

Standard RFC2326, QuickTime/VLC Player etc.

Security

User security authentication, Reset, Hardware Watch Dog

Web Language

Chinese, English

Browser

IE8+, Chrome18+, Firefox5.0+, Safari5.02+

Interface

Ethernet

1 RJ45 10M / 100M Ethernet

4G

LTE-TDD: B34/B38/B39/B40/B41

LTE-FDD: B1/B3/B5/B8

Audio

Built-in Mic and Speaker

SD Card

Support Max. 512GB

Reset Button

Support

General

Power Supply

DC12V/2A

Power Consumption

<9W (During Day); <12W (At Night)

Working Temperature

-20°C ~ 60°C

Working Humidity

10% ~ 90% Rh Non-Condensation

Dimensions

160×303.5×182(mm)

Product Weight

≤746g

Installation

Wall, Ceiling, Pole
