Video |
Image Sensor | 1/2.9" CMOS Sensor |
Max Resolution | 2304 x1296 |
Effective Pixels | 3.0MP |
Compression Standard | H.264/H.265(Default) |
Frame Rate | 12fps(Default), can be set to 5-15 |
Bitrate | Main Stream: 128Kbps ~ 4096Kbps Sub Stream: 68Kbps~1024Kbps |
SNR (dB) | 45dB |
Min. Illumination | 0 Lux (light ON) |
Lens |
Interface Type | M12 |
Lens | 3.6mm |
FOV | H: 81°, V: 44.3°, D: 94.6° |
Function |
Audio Codec | G.711U/G.711A (Default) |
Exposure Control | Auto |
White Balance | Auto |
Gain Control | Auto |
Digital 3D Noise Reduction | Support |
OSD Information Setting | Large Font OSD, OSD Flashing on Alarm, OSD Position Settings |
SNTP | Support |
Schedule Reboot | Support |
Smart Defog | Support |
Face Mode | Support |
Motion Detection | Support (Human, Vehicle) |
Image Setting | Support Saturation, Brightness, Contrast, Sharpness Adjustment |
Image Style | Standard, Soft, Transparent |
Day and Night Function | Automatic Switching, Timing Switching, Day Mode, Night Mode |
Privacy Mask | Support Up To 8 Masking Areas |
Night Vision Optimization | Support |
DWDR | Support |
Screen Settings | Screen Mirroring, Screen Flipping |
Alarm Method | Mobile App Push Notifications |
Audio Function | Built-in Mic and Speaker |
SD Card | Support（512G） |
Reset Button | Support (Reset is not supported in sleep mode) |
Working Mode | AOV Mode: Camera will automatically wake up when a person or car is detected, and the APP can wake up the device. It is in sleep mode in other states; Recording interval in sleep mode: 1 second, 2 seconds (default), 3 seconds, 5 seconds, 10 seconds
Ultra-long Standby Mode: Camera is in sleep mode and only supports APP to wake up the device. The alarm cannot be triggered in this mode; Recording interval in sleep mode: 1 second, 2 seconds (default), 3 seconds, 5 seconds, 10 seconds
High Performance Mode: Camera keeps running |
Network |
Wired Connection | Not Support |
Wireless Connection | 4G LTE-TDD:B34/B38/B39/B40/B41 LTE-FDD:B1/B3/B5/B8 |
Stream | 2x Streams |
Network Transmission | CloudSEE 2.0 |
App | Support iOS/Android |
General |
Lights | 6 White LEDs |
Fill Light Distance | White LED: 35 Meters |
Waterproof Level | IP66 |
Power Supply | DC 5V/2A |
Power Consumption | <0.2W (AOV Mode); <9W (High Performance Mode) |
Working Temperature | -5°C ~ 45°C |
Working Humidity | 10% ~ 90% Rh |
Color/Material | Black and white /Plastic + Metal |
Dimensions (WxHxD) | 135x165.5x250mm |
Weight | 900g |
Installation Method | Wall Mounting, Lifting and Pole Mounting |
