Image Sensor

1/2.9" CMOS Sensor (Dual-Lens AOV architecture, BSI Starlight-grade Sensor)

Max Resolution

2304*1296

Effective Pixels

Dual Lens (3.0MP+3.0MP)

Compression Standard

H.264/H.265(Default)

Frame Rate

12fps(Default), can be set to 5-15

Bitrate

Main Stream: 128Kbps ~ 4096Kbps

Sub Stream: 68Kbps~1024Kbps

SNR (dB)

45dB

Min. Illumination

0 Lux (light ON)

Lens

Interface Type

M12

Lens

Dual lens 3.6mm  F1.0

FOV

H: 81°, V: 44.3°, D: 94.6°

Function

Audio Codec

G.711U/G.711A (Default)

Exposure Control

Auto

White Balance

Auto

Gain Control

Auto

Digital 3D Noise Reduction

Support

OSD Information Setting

Large Font OSD, OSD Flashing on Alarm, OSD Position Settings

SNTP

Support

Schedule Reboot

Support

Smart Defog

Support

Face Mode

Support

Motion Detection

Support (Human, Vehicle)

Image Setting

Support Saturation, Brightness, Contrast, Sharpness Adjustment

Image Style

Standard, Soft, Transparent

Day and Night Function

Automatic Switching, Timing Switching, Day Mode, Night Mode

Privacy Mask

Support Up To 8 Masking Areas

Night Vision Optimization

Support

DWDR

Support

Screen Settings

Screen Mirroring, Screen Flipping

Intelligent Analysis

Not Support

Alarm Method

Mobile  App Push Notifications

Audio Function

Built-in Mic and Speaker

SD Card

Support（Max 512G）

Reset Button

Support (Reset is not supported in sleep mode)

Working Mode

AOV Mode:

Camera will automatically wake up when a person or car is detected, and the APP can wake up the device. It is in sleep mode in other states;

Recording interval in sleep mode: 1 second, 2 seconds (default), 3 seconds, 5 seconds, 10 seconds

Ultra-long Standby Mode:

Camera is in sleep mode and only supports APP to wake up the device. The alarm cannot be triggered in this mode;

Recording interval in sleep mode: 1 second, 2 seconds (default), 3 seconds, 5 seconds, 10 seconds

High Performance Mode:

Camera keeps running

Network

Wired Connection

Not Support

Wireless Connection

4G

LTE-TDD:B34/B38/B39/B40/B41

LTE-FDD:B1/B3/B5/B8

Stream

2x Streams

Network Transmission

CloudSEE 3.0

App

Support iOS/Android

General

Lights

6 White LEDs

Fill Light Distance

White LED: 35 Meters

Waterproof Level

IP66

Power Supply

DC 5V/2A

Power Consumption

<200mW (AOV Mode); <9W (High Performance Mode)

Working Temperature

-10°C ~ 60°C(14℉~140℉)

Working Humidity

10% ~ 90% Rh

Color/Material

Black and white /Plastic + Metal

Dimensions (WxHxD)

177.7x241.8x277.4mm

Weight

NW：1135,GW：2000g(Including batteries, mounting brackets, screw packages, etc.)

Qtg of package

12PCS/Carton,   Carton Size :630x555x590mm

Installation Method

Wall Mounting, Lifting and Pole Mounting
