Image Sensor

1/3" CMOS Sensor

Max Resolution

2560x1792

Effective Pixels

5.0MP

Compression Standard

H.265/H.264

Frame Rate

25fps

Bit Rate

256Kbps~8192Kbps

SNR (dB)

52dB

Min. Illumination

0Lux (IR ON)

Lens

Lens

2.8mm(M12)

FOV

H:100.4°,V:53.9°,D:118.6°

Lights

2 Warm Light LEDs + 2 IR LEDs

IR Distance

IR: Up to 30 Meters

Warm Light: Up to 25 Meters

Function

Exposure Control

Auto

White Balance

Auto

Gain Control

Auto

Image Enhancement

3D DNR

Advanced OSD

Support OSD large font function, OSD flashing on alarm, OSD and time to set the position separately

Motion Detection

Support Humanoid Detection

Image Setting

Flip, Saturation, Brightness, Contrast, Sharpness

Day and night function

Day and night automatic switching

Privacy Mask

Support up to 8 areas

Intelligent Analysis

Region Intrusion Detection, Line Crossing Detection, Video Tampering Detection, Defocus Detection

Alarm Method

Email Alarm,Client Alarm

Remote Operation

System , Audio and video , Image , Alarm , Network management

Expansion Interface

Built-in MIC

Network

Ethernet

10M / 100M Ethernet ,1 RJ45

Stream

2x Streams

Protocols

HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS

ONVIF

standard ONVIF

Network transmission

CloudSEE 2.0, GB28181

Browser

IE8+, Chrome18+, Firefox5.0+, Safari5.02+

User

Up to 13 Users

App

Support iOS/Android

General

Power Supply

DC12V/2A or PoE

Power Consumption

<3W (During day); <6W (At night)

Working Temperature

-30℃~60℃(-22℉~140℉)

Working Humidity

10% ~ 90% Rh

Waterproof

Indoor use only

Material

White/Plastic

Dimensions (WxHxD)

100*84*100(mm)

Weight

220g
