Image Sensor

1/3" CMOS Sensor

Max Resolution

2560x1440

Effective Pixels

4.0MP

Compression Standard

H.264/H.265(Default)

Frame Rate

20fps

Bitrate

Main Stream: 128Kbps ~ 4096Kbps

Sub Stream: 68Kbps~1024Kbps

SNR (dB)

50dB

Min. Illumination

0.01Lux (light ON)

Lens

Interface Type

M12

Lens

2.8mm

FOV

H: 83°, V: 42°, D: 108°

Function

Audio Codec

G.711U/G.711A (Default)

Exposure Control

Auto

White Balance

Auto

Gain Control

Auto

Digital 3D Noise Reduction

Support

OSD Information Setting

Large Font OSD, OSD Flashing on Alarm, OSD Position Settings

SNTP

Support

Schedule Reboot

Support

Smart Defog

Support

Motion Detection

Support Humanoid Detection

Image Setting

Support Saturation, Brightness, Contrast, Sharpness Adjustment

Image Style

Standard, Soft, Transparent

Day and Night Function

Automatic Switching, Timing Switching, Day Mode, Night Mode

Privacy Mask

Support Up To 8 Masking Areas

Night Vision Optimization

Support

DWDR

Support

Screen Settings

Screen Mirroring, Screen Flipping

IP Adaptation

Support Automatic Adaptation of IP Address

Intelligent Analysis

Not support

Alarm Method

Email Alarm, Client Alarm

Remote Operation

System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis

Audio Function

Built-in Mic and Speaker

Storage

Support SD Card（256G）,Cloud Storage

Reset Button

Support

Network

Ethernet

10/100Mbps Ethernet

Wi-Fi

2.4G Hz

Bluetooth Network Configuration

Support

Stream

2x Streams

Network Protocols

HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS

ONVIF

Standard ONVIF

Network Transmission

CloudSEE 3.0

Browser

IE8+, Chrome18+, Firefox5.0+, Safari5.02+

User

Up to 13 Users

App

Support iOS/Android

General

Lights

2 White LEDs + 2 IR LEDs

Fill Light Distance

IR LED:15 Meters

Waterproof Level

IP53

Power Supply

DC 5V

Power Consumption

<6W (During Day); <10W (At Night)

Working Temperature

-30℃~60℃(-22℉~140℉)

Working Humidity

10% ~ 90% Rh

Color/Material

Black and white /PC+ABS

Weight

188g

Installation Method

Wall, Ceiling, Desktop
