JVS-N917-WF
3.0MP Full-Color Video & Audio Wi-Fi Network Camera
Message
Features
Specification
Accessories
Download

Key Features

  • Support Humanoid Detection

  • Built-in Mic and Speaker

  • Equipped With unique VQC (Video Quality Catalyst) Technology

  • Support SD Card (Max. 512GB)

  • IP67 Ingress Protection

Specifications
Video
Image Sensor1/2.9" CMOS Sensor
Max Resolution2304x1296
Effective Pixels3.0MP
Compression StandardH.264/H.265
Framerate25fps
BitrateMain   Stream: 294Kbps ~ 8192KbpsSub   Stream: 58Kbps~ 2356Kbps
Min. Illumination0Lux   (light ON)
Lens
Interface TypeM12
Lens4mm
FOVH   83.4°, V 43.1°, D 99.1°
Functions
Audio CodecG.711U (default)/G.711A
Gain ControlAuto
Digital 3D DNRSupport
OSD SettingLarge   font OSD, OSD flashing on alarm, OSD position settings
Motion DetectionSupport Humanoid Detection
Image SettingSupport Saturation, Brightness, Contrast, Sharpness   adjustment
Privacy MaskSupport up 8 areas
DWDRSupport
Screen SettingsScreen mirroring, Screen flipping
Intelligent AnalysisSupport Region Intrusion Detection, Line Crossing Detection,   Video Tampering Detection
Alarm MethodEmail Alarm, Client Alarm
Remote OperationSystem, Audio and Video, Image, Alarm, Network management,   Storage management, Intelligent Analysis
Audio FunctionBuilt-in Mic and Speaker
SD CardSupport(512GB)
VQC TechnologySupport
Network
Ethernet10/100Mbps Ethernet
Wi-FiIEEE 802.11 b/g/n 2.4GHz
Stream2x   Streams
Network ProtocolsHTTP,   TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
ONVIFStandard   ONVIF
Network TransmissionCloudSEE 2.0
BrowserIE8+,   Chrome18+, Firefox5.0+, Safari5.02+
UserUp   to 13 Users
AppSupport iOS/Android
General
Lights3   White LEDs + 3 IR LEDs
IR DistanceUp to 30 Meters
Waterproof LevelIP67
Power SupplyDC12V
Working Temperature-20°C   ~ 60°C
Working Humidity10%   ~ 90% Rh
Color/MaterialBlack   and White/Plastic and Metal
Installation MethodWall   or ceiling mount
