JVS-FR3022
2.0MP Face Capture PoE Dome Camera
Message
Features
Specification
Accessories
Download
Key Features

• Resolution 1920x1080@30fps.

• Ingress Protection IP66.

• PoE IEEE 802.3af.

• 18x IR-LED, Up to 20 Meters.

• ONVIF 2.4, Compatible with ONVIF Recorder.

• Support Face Capture function

Specifications

ModelJVS-FR3022
Video
Image Sensor1/2.9” CMOS
Max Resolution1920x1080
Effective Pixels2.0MP
Compression StandardH.265/H.264
Maximum Frame Rate1080p@30fps / 960p@30fps
SNR(dB)52.1dB
Bit Rate Main: 25～8129Kbps Sub: 25~4068Kbps
Illumination0Lux(IR On)
Lens
Lens8mm
Viewing AngleH:38.3°  V:28.9°  D:47.5°
IR-LEDs18x IR LEDs
IR-DistanceUp to 20 Meters
Function
Motion DetectionSupport
Email AlertSupport
Day& NightSupport
RecordingSupport (NVR, Windows PC, Smartphone)
DHCPSupport
Audio InputSupport (Ext. Mic)
Audio CodecSupport (G711A/G711U)
Privacy MaskSupport up 8 areas
Exposure ControlSupport
Image AdjustmentSupport
Auto. White BalanceSupport
Image RotationSupport (Mirror/Flip)
IntercomNot Supported
Face capture

Supports detection, tracking, capture, screening, and output of optimal face capture,

 human traffic statistics, heartbeat mode With DeepCloud Platform

Capture resolution1920x1080
Maximum face per frame                   32
Image FormatJPEG
Upload methodPrivate protocol, HTTP upload, FTP upload
Capture modeAfter taking off capture, track process capture, mix capture, interval capture
Network
Ethernet10M/100M Ethernet, RJ45 Port
ProtocolsHTTP, TCP/IP,UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
Stream2x Streams
LANSupport
ONVIFONVIF 2.4
UserUp to 13 Users
BrowserIE8+
Smart PhoneiOS/Android
General
Dimensions (WxHxD)φ120x90 (mm)
Weights500g
MaterialAluminum
Working Temperature-20°C～60°C
HumidityRH 10%～90%
Power SupplyDC12V/2A, PoE (IEEE 802.3af)
ConsumptionDay ≦3W; Night ≦7W
WaterproofIP66


Dimensions (mm)



JVS-FR3022 2.0MP Face Capture PoE Dome Camera.pdf
