JVS-N537-SDL
5.0MP Full-Color Video & Audio PoE Network Camera
Message
Features
Specification
Accessories
Download

Features

  • Spotlight on Motion Detection

  • Full-Color with Dual Smart Illumination

  • Support Humanoid Detection

  • Built-in Mic and Speaker

  • With built-in PoE

  • Equipped With unique VQC (Video Quality Catalyst) Technology

  • Support 512GB SD Card

Specifications
Video
Image Sensor1/3" CMOS Sensor
Max Resolution2560x1792
Effective Pixels5.0MP
Compression StandardH.264/H.265
Framerate25fps
BitrateMain   Stream: 317Kbps ~ 8MbpsSub   Stream: 68Kbps~2728Kbps
SNR (dB)52dB
Min. Illumination0Lux   (light ON)
Lens
Interface TypeM12
Lens2.8mm
FOV2.8mm:H   96°, V 53°, D 110°
Function
Audio CodecG.711U/G.711A (default)
Exposure ControlAuto
White BalanceAuto
Gain ControlAuto
Digital 3D Noise   ReductionSupport
OSD Information SettingLarge   font OSD, OSD flashing on alarm, OSD position settings
SNTPSupport
Schedule RebootSupport
Smart DefogSupport
Motion DetectionSupport Humanoid Detection
Image SettingSupport Saturation, Brightness, Contrast, Sharpness   adjustment
Image StyleStandard, Soft, Transparent
Day and Night FunctionAuto, Always Black & White, Always Color, Scheduled   Color
Privacy MaskSupport up 8 areas
Night Vision   OptimizationSupport
DWDRSupport
Screen SettingsScreen mirroring, Screen flipping
IP AdaptationSupport automatic adaptation of IP address (Optional)
Intelligent   AnalysisSupport Region Intrusion Detection, Line Crossing Detection,   Video Blocking Detection, People Counting
Alarm MethodEmail Alarm, Client Alarm
Remote OperationSystem, Audio and Video, Image, Alarm, Network management,   Storage management, Intelligent Analysis
Audio FunctionBuilt-in Mic and Speaker
SD CardSupport 512GB
VQC TechnologySupport
Network
Ethernet10/100Mbps Ethernet
Stream2x   Streams
Network ProtocolsHTTP,   TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
ONVIFStandard   ONVIF
Network TransmissionCloudSEE 2.0
BrowserIE8+,   Chrome18+, Firefox5.0+, Safari5.02+
UserUp   to 13 Users
AppSupport iOS/Android
General
Lights2   White LEDs + 2 IR LEDs
IR DistanceUp to 30 Meters
Waterproof LevelIP67
Power SupplyDC12V or PoE (IEEE802.3af)
Power Consumption<4W   (During Day); <6W (At Night)
Working Temperature-25°C ~ 55°C
Working Humidity5% ~ 95% Rh
Color/MaterialWhite/Plastic+Metal
Dimensions (WxHxD)106x94x106mm
Weight320g
Installation MethodWall or ceiling mount
