JVS-ND7916-DV
16CH H.265 4x SATA NVR
Message
Features
Specification
Accessories
Download

Key Features



  • Support 4K Output

  • Support 4K IP Cameras Input

  • Support Audio Input and Output;

  • Support Alarm Input and Output, 6 In 1 Out

  • Support 4x SATA , Up to 10TB Each

  • Support RS485


Video & Audio
IP Camera Input16 Channel
Video OutputHDMI: 3840*2160/2560*1440/1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768

VGA: 1920x1080/1440*900/1280*1024/1280*720/1024*768
Max Decoding4K/5.0MP/ 4.0MP/ 1080P/ 960P/ 720P 30fps
Audio In & OutSupport
CompressionH.265/ H.264
Bandwidth I/O320Mbps/160Mbps
Storage
SATA4x SATA Interface
CapacityUp to 10TB Max.
File FormatLog: *.txt/ Picture: *.JPG/ Video: *.mp4
Backup ModeUSB Device FAT32
Video
Video PlaybackAuto/ Timing/ Alarm/ Motion Detection/ Intelligent Analysis
Sync Playback1ch 4K, 2ch 5.0MP, 3ch 4.0MP, 4ch 3.0MP,4ch 1080P
Search ModeChannel Number/ Recording Type/ Date
Network
Ethernet100/1000Mbps
Network FunctionTCP/IP, UDP, SMTP, NTP, DHCP
InteroperabilityONVIF 2.4, CloudSEE 2.0
Smart PhoneiPhone, Android
Hardware
Network Interface2x RJ45
USB Interface3x USB2.0
PTZ InterfaceRS485
Controlling DeviceMouse
Alarm Input6CH
Alarm Output1CH
Special
Multi-Screen Display1/ 4/ 5/ 6 up to 16
Alarm MethodBuzzer, Push to App, Email Alarm, External Alarm
Digital ZoomSupport
General
Power SupplyDC 12V
Consumption≤ 20 W (Without HDD)
Working Temperature-10°C ~ 55°C
Working Humidity10% ~ 90%
Dimensions445*45*320(mm)
Weight≤5Kg (Without HDD)
