| Video |
| Image Sensor | 1/2.82" CMOS Sensor |
| Max Resolution | 3840*2160 |
| Effective Pixels | 8.0MP |
| Compression Standard | H.264/H.265 |
| Framerate | 25fps |
| Bitrate | Main Stream: 256Kbps ~ 10MbpsSub Stream: 68Kbps~3072Kbps |
| SNR (dB) | 49.3dB |
| Min. Illumination | 0Lux (light ON) |
| Interface Type | M12 |
| Lens | 3.6mm |
| FOV | 3.6mm:H 87.8°, V 43.4°, D 105° |
| Function |
| Audio Codec | G.711U/G.711A (default) |
| Exposure Control | Auto, HLC, BLC |
| White Balance | Auto |
| Gain Control | Auto |
| OSD Information Setting | Large font OSD, OSD flashing on alarm, OSD position settings |
| SNTP | Support |
| Schedule Reboot | Support |
| Smart Defog | Support |
| Motion Detection | Support Humanoid Detection & Vehicle Detection |
| Image Setting | Support Saturation, Brightness, Contrast, Sharpness adjustment |
| Image Style | Standard, Soft, Transparent |
| Day and Night Function | Auto, Always Black & White, Always Color, Scheduled Color |
| Privacy Mask | Support up 8 areas |
| Night Vision Optimization | Support |
| WDR | Support |
| Screen Settings | Screen mirroring, Screen flipping |
| IP Adaptation | Support automatic adaptation of IP address (Optional) |
| Alarm Method | Email Alarm, Client Alarm |
| Remote Operation | System, Audio and Video, Image, Alarm, Network management |
| VQC Technology | Support |
| SAFE Function | Support |
| Network |
| Ethernet | 10/100Mbps Ethernet |
| Stream | 2x Streams |
| Network Protocols | HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS |
| ONVIF | Standard ONVIF |
| Network Transmission | CloudSEE 2.0 |
| Browser | IE8+, Chrome18+, Firefox5.0+, Safari5.02+ |
| User | Up to 13 Users |
| App | Support iOS/Android |
| General |
| Lights | 6 White LEDs + 6 IR LEDs |
| IR Distance | Up to 60 Meters |
| White Led Distance | Up to 50 Meters |
| Waterproof Level | IP67 |
| Power Supply | DC12V or PoE (IEEE802.3af) |
| Power Consumption | <12W |
| Working Temperature | -20°C ~ 60°C |
| Working Humidity | 5% ~ 93% Rh |
| Color/Material | Black & White/Metal + Plastic |
| Dimensions (W x H x D) | 94.5x94x174.5mm |
| Weight | 450g |
| Installation Method | Ceiling Mount, Wall Mount |
