IP Camera Input

64 Channel

Video Output

HDMI: 4K@60Hz/ 4K@30Hz/ 2K@60Hz/ 2K@30Hz/ 1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768

VGA: 1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768

Max Decoding

12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/720p

Audio In & Out

Support

Decoding Format

Decoding Format H.265/H.264/H.264+

Bandwidth I/O

400Mbps/320Mbps

Storage

SATA

8x SATA Interface

Capacity

Up to 10TB Max.

File Format

Log: *.txt/ Picture: *.JPG/ Video: *.mp4

Backup Mode

USB 3.0 Device FAT32/ NTFS/ exFAT

Raid

RAID0, RAID1, RAID5, RAID6 and RAID10

Video

Video Playback

Auto/ Timing/ Alarm/ Motion Detection/ Intelligent Analysis

Sync Playback

4CH 4K/9CH 5.0MP/ 11CH 4.0MP/ 13CH 3.0MP/

16CH 2.0MP

Search Mode

Channel Number/ Recording Type/ Date

Network

Ethernet

100/1000Mbps

Max. Remote Channels

128 LAN/ 64 WAN

Network Function

PPPoE , NTP, UPnP

Interoperability

ONVIF 2.4, CloudSEE 2.0

Smart Phone

iPhone, Android

Hardware

Network Interface

2x RJ45

USB Interface

3x USB2.0, 1xUSB3.0

PTZ Interface

RS485

Controlling Device

Mouse

Alarm Input

16CH

Alarm Output

4CH

Others

Smart Search option, Support VCA Search, Connectable to the Third-Party Network Camera

Special

Multi-Screen Display

1/ 4/ 5/ 6 up to 64

Alarm Method

Buzzer, Push to App, Email Alarm, External Alarm

Digital Zoom

Support

General

Power Supply

ATX

Consumption

≤ 30 W (Without HDD)

Working Temperature

-10°C ~ 55°C

Working Humidity

10% ~ 90%

Dimensions

445x90.5x430(mm)

Weight

≤ 8Kg (Without HDD)
